Container de stocare a energiei BRES-645-300, capacitate baterie: 645 kWh, capacitate PCS: 300 kW, include 3 module bidirectionale AC/DC 100 kW, 1 STS, 3 baterii LFP 768V 280Ah 215kWh, PMS (PCS Management System), transformator de izolare 300kW, 3 HVAC, sistem de stingere a incendiilor, dimensiuni (latime*adancime*inaltime): 3000*2438*2591 mm

Model	BRES-645-300
PV parameter
Maximum photovoltaic access power	200kW
Rated current	303A
Rated input voltage	3W+N+PE, 380/400V
Rated frequency	50Hz/60Hz
DC side parameter
Voltage range	DC580V~DC900V
DC channel	3
Rated single channel current	170A
AC parameter (on-grid)
Rated power	300kW
Rated grid voltage	3W+N+PE, 380V/400V
Grid voltage range	-15% ～ +10%
Rated grid frequency	50Hz/60Hz
Grid frequency range	±2Hz
Output current harmonics	≤3% (rated power)
DC component	＜0.5%In
Power factor range	-0.9 ~ +0.9
AC parameter (off grid)
AC parameter (off grid)	300kW
Maximum output power	315kVA
Rated output voltage	3W+N+PE, 380/400V
Output voltage harmonics	3%
Rated frequency	50Hz/60Hz
Overload capacity	105%: continuous operation; 105%－120%: 10 min; 120%: 1 min
Battery parameter
Cell type	Lithium iron phosphate
Single battery cabinet electricity	215.04kWh
Number of battery cabinets	3
Battery system electricity	645.12kWh
Rated running time	2 h (the duration can be customized by adjusting the number of battery modules)
Cycle life	6000 times (0.5C @ 25°C charge and discharge @ 90% DOD, EOL 80%)
Protection
AC switch	Equipped
PV electrically-operated AC switch	Equipped
Grid monitoring	Equipped
Surge protection	Equipped
Basic parameter
Size (W*D*H) (mm)	3000*2438*2591
Weight (kg)	10000Kg
Isolation mode	Isolation transformer (built-in)
On-grid and off grid switching device	STS (electronic switch)
Protection grade	IP54 for outdoor type
Working temperature range	-20°C - 55°C (derating above 45°C)
Relative humidity (without condensing)	0 ~ 95%
Temperature control method	Battery compartment: air conditioning; Electrical compartment: air cooling
Maximum working altitude	2000m at 45°C; 2000m－4000 m with derating use
Display	Touch screen
External communication interface	RS485, LAN
Communication protocol	Modbus-RTU, Modbus-TCP
